94 v0 circuit board from China manufacturer - Shenzhen Tianweisheng Electronic Co., Ltd.

Price:	0.1~0.5 USD
Payment Terms:	T/T,D/P;Papal
Place of Origin:	Guangdong, China (Mainland)


	Add to My Favorites
HiSupplier Escrow	Share \|

Product Detail

Model No.: tws012-K012

Production Capacity: 300000 Square Meter/Square...

Delivery Date: 10-15 working days for mass...

Brand Name: tws

Copper Thickness: 1oz

Min. Hole Size: 0.15mm

Min. Line Spacing: 0.2mm

Hole Position Deviation: ±0.05mm

PCB Standard: IPC-A-610 D

Minimun thickness of soldermask: 10um

Certification: ROHS/UL/ISO9001

OEM&ODM: One-stop service

Means of Transport: Ocean,Land,Air;DHL,UPS

Packing: vacuum package+carton box

Number of Layers: 8-Layer

Base Material: fr4

Board Thickness: 1.6mm

Min. Line Width: 0.2mm

Max. board size: 800*800mm

Warp: ≤0.7%

Solder mask: Green/ White/ Black/ Blue/ ...

Type of Assembly: SMT,Thru-hole

PCB experience: 20years

1.94v0 circuit board
2.UL,RoHS,SGS certification
3.Matrial:BT/FR-4
4.Compatitive price,T/T&Paypal
5.OEM circuit board

94 v0 circuit board
o PCB board file with parts list provided by customers
o PCB board made, circuit board parts purchased by us
o PCB board with parts assembled
o Electronic testing circuit board or PCBA
o Fast delivery, anti-static package
o RoHS Directive-compliant, lead-free
o One stop service for PCB design, PCB layout, PCB manufacture, components purchasing,

PCB assembly, test, packing and PCB delivery

Technical Specification For PCB

Number of Layer	1,2,4 or 6,upto 18 layer
Order Quantity	1 to 50,000
Board Shape	Retangular,round,slots,cutouts,complex,irregular
Board Type	Rigid, Flexible, Rigid-flexible
Board Material	FR-4 glass epoxy, FR-4 high Tg, Rohs compliant,Aluminum,Rogers,etc.
Board Cutting	Shear,V-score,Tab-routed
Board Thickness	0.2-4.0mm, Flex 0.01-0.25mm
Copper Weight	1.0, 1.5, 2.0 oz
Solder Mask	Double-sided green LPI,Also support Red,White,Yellow,Blue,Black
Silk Screen	Double-sided or single-sided in white,yellow,black,or negative
Silk Screen Min Line Width	0.006'' or 0.15mm
Max Board Dimensions	20 inch20inch or 500mm500mm
Min Trace/Gap	0.10mm, or 4mils
Min Drill Hole Diameter	0.01'',0.25mm, or 10mils
Surface Finish	HASL,Nickle,Immersion Gold,Immersion Tin,Immersion Silver,OSP,etc.
Board Thickness Tolerance	±10%
Copper Weight Tolerance	± 0.25 oz
Minimal Slot Width	0.12'', 3.0mm, or 120mils
V-Score Depth	20-25% of board thickness
Design File Formate	Gerber RS-274,274D,Eagle and AutoCAD's DXF,DWG

PCB Assembly Capabilities

Quantity	Prototype&Low Volume PCB Assembly,from 1 Board to 250,is specialty,or up to 1000
Type of Assembly	SMT,Thru-hole
Solder Type	Water Soluble Solder Paste,Leaded and Lead-Free
Components	Passive Down to 0201 size BGA and VFBGA Leadless Chip Carriers/CSP Double-sided SMT Assembly Fine Pitch to 0.8mils BGA Repair and Reball Part Removal and Replacement
Bare Board Size	Smallest:0.250.25 inches Largest:2020 inches
File Formate	Bill of Materials Gerber files Pick-N-Place file
Types of Service	Turn-key,partial turn-key or consignment
Component packaging	Cut Tape,Tube,Reels,Loose Parts
Turn Time	Same day service to 15 days service
Testing	Flying Probe Test,X-ray Inspection AOI Test
PCB assembly process	Drilling-----Exposure-----Plating-----Etaching & Stripping-----Punching-----Electrical Testing-----SMT-----Wave Soldering-----Assembling-----ICT-----Function Testing-----Temperature & Humidity Testing

Detailed Terms for Pcb Assembly

Technical requirement for pcb&pcb assembly:
---- Professional Surface-mounting and Through-hole soldering Technology
---- Various sizes like 1206,0805,0603 components SMT technology
----ICT(In Circuit Test),FCT(Functional Circuit Test) technology.
----PCB Assembly With UL,CE,FCC,Rohs Approval
----Nitrogen gas reflow soldering technology for SMT.
----High Standard SMT&Solder Assembly Line
---- High density interconnected board placement technology capacity.

Quote requirement for pcb&pcb assembly:
----Gerber file and Bom list
----Clear pics of pcba or pcba sample for us
----Test method for PCBA

94 v0 circuit board
