Aluminum PCB board LED from China manufacturer - Shenzhen Tianweisheng Electronic Co., Ltd.

Price:	0.02~0.3 USD
Payment Terms:	T/T,L/C,WU
Place of Origin:	Guangdong, China (Mainland)


	Add to My Favorites
HiSupplier Escrow	Share \|

Product Detail

Model No.: tws-2013070107

Production Capacity: 10000 square meter

Delivery Date: 5-7 working days

Base Material: AL

Board Thickness: 1.6mm

Min. Line Width: 0.2mm

Surface Finishing: HASL,ENIG,OSP,immersion gol...

contouring: milling and V-cut

Tolerance of finished panel thickness: +/-10%

Certification: UL,ISO

Name: Aluminum PCB board for Elec...

Means of Transport: Ocean,Land,Air

Packing: vacuum plastic and carton, ...

Brand Name: TWS

Copper Thickness: 1OZ

Min. Hole Diameter: 0.2mm

Min. Line Spacing: 0.1mm

color: all colours

Shape tolerance: +/-0.13

Standard: IPC-A-610D

legend colour: Black or White

Aluminum PCB board LED
Reasonalble Price
Fast delivery Aluminum pcb
.Reputable PCB manufacturer
RoHS complaint PCB Board

Aluminum PCB board for Electronic LED Products

------Tianweisheng Electronic Co.,Ltd

technologyproject	making ability and technologystandard
Certificate	ISO9001,ISO14001, UL
Surface Finishing	Plating Nickel and immersion Gold, Hot Air (HASL), HASL Lead Free,OSP, Immersion Tin
Max.panel size	600mm*700mm
Min.panel size	5mm*5mm
Boardwarpage	single side<=1.0% double side<=0.6% multi-layer<=0.6%
Min.Thickness	0.2mm±0.08mm
Min.Line width	HASL board 0.07mm±20%(2mil±20%)
Min.line space	immersion Gold 0.075mm±20%(2mil±20%)
copperfoil to board sidespacing	0.5mm
hole sideto linesidespacing	0.3mm
Min hole size	0.2mm
copper thinckness of Hole	20-35um
Tooling hole tolerance	±0.076mm
Min.stamping round hole diameter	FR-4 board thinckness 1.0mm(40mil)under 1.0mm(40mil)
Min.stamping round hole diameter	FR-4 board thinckness1.2-3.0mm(47mil-120mil)1.5mm(59mil)
Min.stamping square hole specification	FR-4.CEM-3 board thinckness 1.0mm(40mil) under 0.8mm x0.8mm(31.5mil x 31.5mil)
Min.stamping square hole specification	FR-4.CEM-3 board thinckness 1.2mm - 3.0mm(47mil-120mil) 1.0mm x1.0mm(40mil x 40mil)
tracedeviation	±0.076mm(±3mil)
Molding size tolerancelimit	CNC milling profile ±0.15mm(±6mil); die profile±0.15mm(±6mil)
V-CUT registration accuracy	±0.2mm(±8mil)
producttype	single sidedouble side multi-layer and flexibleboard
Base Material	FR-4,CEM-1, CEM-3, High frequency, aluminium basedboard
processthinckness	0.2-3.5mm
base materialcopperthinckness	18um, 35um, 70um, 105 um
Min.hold diameter	0.2mm
platingthinckness	plating gold Ni2.5-5um, Au0.05-0.10um
platingthinckness	immersion gold Ni5-8um, Au0.08-0.12um
platingthinckness	finger gold Ni2.5-5um, Au0.05-0.12um
processability	20000 square meters/month
profileprocess	die CNC machine
V-CUT horntolerance	±5°
V-CUT board materialthinckness	0.6mm - 3.2mm (15.5mil - 129.58mil)
Min.SMD space	0.3mm (12mil)
Min.component markingfont	0.15mm (5.79mil)
Min. single side solder annular width(production)	0.15mm (5.79mil)
Min. cross-hatchingpad	0.076mm (0.3mil)
Min.soldermask brigde	±0.076mm(±3mil)
Carbonink board making data	1)1.0 high impedance control limit:20K±10%
	2)2.0 hardness:6H
	3)3.0 can bear friction time:over200000

We canoffer:

Rigid PCB(Single-sided PCB, Double-sided PCB, Multi-layer PCB)

-Rigid-flexiblePCB

-FlexiblePCB

-HDIPCB

-All kinds ofhigh class PCB

- Product Design

- Prototyping

- Cable and Wire Assemblies

- transformerand led lights

Application:

OurPrinted circuit board can be used for a wide range of applications in

Electronicproducts such as Communication equipments, Computer, Auto electronics, Medicaldevices, Measurement and Control systems, Aviation and Military equipment andLED lighting etc.

Qualitycontrol:

1.100% inspected before shipped.

2.Follow IPC-TM-650 perform reliability test.

3.Solderability test and thermal stress test.

4.Process control: QC and QA.

5.Apply for Certificate: UL, ISO9001, ISO14001.

Packing:

1. Innerpacking: Vacuum packing / Plastic bag.
2. Outer packing: Standard cartonpacking.
Aluminum PCB board for Electronic LED Products
