led panel light pcb with UL/ CE/RoHS certification

Price:	1.0~50.0 USD
Payment Terms:	T/T,L/C,WU,
Place of Origin:	Guangdong, China (Mainland)


	Add to My Favorites
HiSupplier Escrow	Share \|

Product Detail

Model No.: tws-pll-003

Production Capacity: 120000 Square Meter /Month

Delivery Date: 3-15 working days after you...

Base Material: Alluminum pcb/ FR4

Board Thickness: 0.2mm-7mm

Min. Line Width: 0.075mm(3mil)

Surface Finishing: HALS/HALS lead free,Chemica...

Solder Mask: green/red/blue/white/yellow

Certification: UL/SGS/ROHS

Warp&Twist: 0.7%

OEM/ODM: One-stop service

Means of Transport: Ocean,Air,

Packing: vacuum packaging and carton...

Brand Name: TWS

Copper Thickness: 0.5-4.0oz

Min. Hole Diameter: 0.25mm

Min. Line Spacing: 0.075mm(3mil)

Layer: 1-28 Layer

MAX.Board Size: 9200*900mm

Controlled impedance: ±5%

Rang of finish boards thickness: ±10%

PCB standard: IPC-A-610D

led panel light pcb with good quality
1.low power consumption
2.uniform luminance& no glare
3.UL&CE&ROHS approval
4.best heat dissipation

Low power consumption,uniform luminance 600*600 LED panel light

Product Name	Product Type	Color	Lumen	Power	Voltage
standard European style	HS-PE/PA-CC/CV3528CW-S	CW	3520LM	42W	DC24V
	HS-PE/PA-CC/CV3528W-S	W	3466LM
	HS-PE/PA-CC/CV3528WW-S	WW	2440M

led panel pcb 600x600mm SMD3014/5050/3528 CE,ROHS,FCC,UL Approval led light

1. Beautiful appearance, elegant, lightweight

2. Energy saving and low power consumption;

3.Instant start, no flickering ,no humming;

4.Special different view angles, mixing lighting design;

5.Dimmable,one dimmer can control hundreds of panel lights

6.Absolutely thin, Light body thickness of only 11MM

7.New design for diversified environment application

8.Special different vision angle, the design diversification.

9.No infrared rays, no ultraviolet radiation, no thermal effect

10.Lighting comes all around into light guide panel, more efficient dissipation

led panel pcb 600x600mm SMD3014/5050/3528 CE,ROHS,FCC,UL Approval led light

1.product category:standard ledpanel light, European style led panel light, ajustable color teperature led panel
2.product type:HS-PA-CV3528-N

3.output voltage:DC24V
4.work current:0.7AOR 1.4A
5.Color of led panel:single color(Warm White,White),RGB, ajustable color temperature
6.product power:single color 42W

7.Work temperature:-20-60°C
8.led panel size:595*595mm
9.Thickness of led panel:10mm
10.LED source:SMD3528 or3014 LED

11.installion way: recessed, Ceiling type, lift onlift-off type , keel-like type

led panel pcb 600x600mm SMD3014/5050/3528 CE,ROHS,FCC,UL Approval led light

Hotel, meeting room, factory, office, commercial complexes, residential & institution buildings, school and hospital, place where need energy saving and high CRI index lighting etc.

led panel pcb 600x600mm SMD3014/5050/3528 CE,ROHS,FCC,UL Approval led light

1.use the side light technology, differ from the traditional led panel light.
2.can not see LED spot, can be ultrathin to 1cm
3.uniform luminance, no glare, use the advanced diffuser plate and Light guide plate.
4.low power consumption,high energy saving,low voltage, high brightness
5.aluminum profile shell,good heat dissipation,no safty worries.

1.Payment: T/T 30% deposit, T/T 70% before shipment,Western Union, Paypal
2.Sample can be supplied
3.Shipping freight are quoted under your requests
4.Shipping port: Shenzhen, Mainland China
5.Discounts are offered based on order quantities

.your inquiries will be dealed with within 24 hours

2.widely sales network and excellent salesman team for your service

3.monthly capacity of 100,000units ,so,do not worry about the suplyablity.

4.spare for each order

5.OEM&ODM, any your customized lightings we can help you to design and put out into product.
6.Protection of your sales area, ideas of design and all your private information.
