double side pcb board in China from China manufacturer - Shenzhen Tianweisheng Electronic Co., Ltd.

Price:	57.0~200.0 USD
Payment Terms:	T/T,L/C,D/A,D/P,WU,
Place of Origin:	Guangdong, China (Mainland)


	Add to My Favorites
HiSupplier Escrow	Share \|

Product Detail

Model No.: TYG036

Production Capacity: 1000square meter/per day

Delivery Date: 3~10days

Independence tolerance: +/-18%

Layer count: 1-24

Gold finger: Ni: 80~250u", Au: 1~5u"

Via plug: Max via size: 24mil (0.6mm)

Certification: UL/SGS/ROHS

Means of Transport: Ocean,Land,Air,

Packing: Inner vacuum and plastic pa...

Max pane size: 34"*25"

Aspecr Ratio: 10:7

Solder mask abrasion: ≥10H

Warp and twist: ≤0.55%

Peel Strength: 1.4N/mm

1.Base Material:Aluminum pcb
2.copper thickness:0.5OZ
3.board thickness:1mm
4.Surface treatment:HASL
5.layer:1~18

Specifications

1. pcb board
2.immersion gold surface finishing
3.short delivery time
4.small order are vailabe
5.OEM areprovided

Why do youchoose Huagao?

1. We have 9 years experienceprofessional PCB manufacturer.

2. Welcome your design, your logo can beprinted in the PCB.

3. We offer MOQ and samplingservice.

4. Our capacity can be 1200 squaremeter/square meters per month.

5. Sold makes types are according to yourrequirement (any color are available).

OurPCB Vision

Be the most reliable PCB and PCBA servicesupplier.

OurPCB Mission

1.Dedicate to satisfy customers'needs.

2.Provide high qualityproducts

3.Provide most professionalservices.

4.Deliver products ontime.

5.Keep all costs to minimum and maximizeour customers' benefits.

The PCB capability

We focus on high quality including quickturn PCB prototype , small volume, mid &Big volume PCB.

Capability:

-High Frequency (TACONICmaterial)/TG/Density/precision impedance controlled boards

-Heavy Copper PCB, Metal basedPCB. Hard Gold PCB, Blind &Buried vias boards,

Halogen Free PCB, Aluminum-backedBoards

-Gold finger+ HAL & Leadfree HASL PCB, Leadfree compatible PCB

Our Productrange
We offer a wide range ofPCBs such as single-sided, double-sided, multi-layer, high frequency, MCPCB,metal-backed PCB and so on.

We can do foryou:

1-16 layer FR-4 PCB board, 1-2 layerAluminum PCB

1-6 oz copperthickness

0.2 mm hole size

0.1 mm linewidth/space

OurPCB are using for wide range of electronic products, such as project, amplifier,CCTV, power supply, GPS, Safety ,camera, set-top box, medical device,Telecommunication, LED light and so on.

3, How can we helpyou?
What we offer is bettersolutions to help you improve your quality while maintaining low production costand be your longtime partner.

4, Can I ask you threequestions?
(1)Do you have plans toimport printed circuit board this year?
(2)If so, do you have plan to findan supplier in China?
(3)How can I Be a qualified supplier foryou?

Ifour PCBs can meet your requirements,welcome to receive your enquiry or trialorder for testing our price and quality. We will quote to you the best price foryour reference as soon as we receive your specific inquiry.

ManufacturerCapability

Material	FR-4 / Hi Tg FR-4 / Lead free Materials(RoHS Compliant) /CEM-3, Aluminium, Metal based
Layer No.	1-16
Finished Boardthickness	0.2 mm-3.8mm(8 mil-150mil)

Board ThicknessTolerance	±10%
Cooper thickness	0.5 OZ-6OZ (18 um-210um)
Copper Plating Hole	18-40 um
Impedance Control	±10%
Warp&Twist	0.70%
Peelable	0.012"(0.3mm)-0.02 (0.5mm)
Images
Min Trace Width (a)	0.075mm (3mil)
Min Space Width (b)	0.1mm (4 mil)
Min Annular Ring	0.1mm (4 mil)
SMD Pitch (a)	0.2 mm(8 mil)
BGA Pitch (b)	0.2 mm (8 mil)
	0.05mm
SolderMask
Min Solder Mask Dam(a)	0.0635 mm (2.5mil)
Soldermask Clearance(b)	0.1mm (4 mil)
Min SMT Pad spacing(c)	0.1mm (4 mil)
Solder MaskThickness	0.0007"(0.018mm)
Holes
Min Hole size (CNC)	0.2 mm (8 mil)
Min Punch Hole Size	0.9 mm (35mil)
Hole Size Tol (+/-)	PTH:±0.075mm;NPTH:±0.05mm
Hole Position Tol	±0.075mm
Plating
HASL	2.5um
Lead free HASL	2.5um
Immersion Gold	Nickel3-7um Au:1-5u''
OSP	0.2-0.5um
Outline
Panel Outline Tol(+/-)	CNC: ±0.125mm, Punching:±0.15mm
Beveling	30°45°
Gold Finger angle	15° 30° 45°60°
Certificate	ROHS,ISO9001,CE,ULcertificate.

Advanced ProductionEquipment
electronic PCB manufacturer and pcb assembly

Product HighQuality Perfect
electronic PCB manufacturer and pcb assembly

Meet your need is ourgreatest pursuit .If you are looking for a pcb board manufacturerinchina,Pleasegive us your files ofpcb for a quote (Gerberfiles and specification),I will reply email in 3hours. Youalso cancontact usby .

1.Advanced production lines andprofessional staff.

2.Honesty credibility in china'stop.

3.Competest price but highquality.

4. One-stopservice.

5.Delivery ontime.
electronic PCB manufacturer and pcb assembly
