HDI pcb/ printed circuit board made in China from China manufacturer - Shenzhen Tianweisheng Electronic Co., Ltd.

Product Detail

Model No.: tws-pll-2013073002

Production Capacity: 120000 Square Meter /Month

Delivery Date: 5-15 working days after you...

Brand Name: TWS

Copper Thickness: 0.5-4OZ

Min. Hole Size: 0.2mm

Min. Line Spacing: 0.1mm

Solder Mask: green/red/blue/white/yellow

Certification: UL/SGS/ROHS

Warp&Twist: 0.7%

Impedance control: ±10%

PCB standard: IPC-A-610D

Means of Transport: Ocean,Land,Air

Packing: vacuum packaging and carton...

Number of Layers: 8-Layer

Base Material: aluminum/fr4/CEM-1/CEM-3

Board Thickness: 0.2-4.0mm

Min. Line Width: 0.1mm

Layer: 1-28 Layer

MAX.Board Size: 900*900mm

Controlled impedance: ±5%

Rang of finish boards thickness: 0.21~7.0mm

OEM/ODM: One-stop service

HDI pcb
1.No MOQ request.
2.Advanced equipment.
3.Final pcb functional testing.
4.20 years experience

Round LED PCB /led lamp pcbLED PCB CIRCUIT BOARD

1. Lead Free HAL PCB
2.UL,SGS,ROHS,IS09001,CEC
3.Fast delivery with high quality
4.20years in Pinted circuit board

1	layer	1-12 layer
2	Material	FR-1,FR-2,FR-4,CEM-1,CEM-3,Hight TG,FR4 Halogen Free,Aluminum material
3	Board thickness	0.2mm-7mm
4	Max panel size	630mm*520mm
5	Min.drilled hole size	0.25mm
6	min.line width	0.075mm(3mil)
7	min.line spaceing	0.075mm(3mil)
8	Surface finish/treatment	HALS/HALS lead free,Chemical tin,Chemical Gold,Immersion gold Inmersion Silver/Gold,Osp,Gold Plating
9	Copper thickness	0.5-4.0oz
10	Solder mask color	green/black/white/red/blue/yellow
11	Inner packing	Vacuum packing,Plastic bag
12	Outer packing	standard carton paking
13	Hole tolerance	PTH:±0.076,NTPH:±0.05
14	Certificate	UL,ISO9001,ISO14001,ISO/TS16949,ROHS
15	profiling punching	Routing,V-CUT,Beveling
16. providing you one-stop pcb assemblies service.
